Flow Comparator
The Accumax Flow Comparator monitors two flow sensors at once - typically inlet against outlet - and alarms on the outlet-to-inlet recovery rate. A single compact, display-equipped unit therefore covers both measurement and control across two measuring points. It offers RS485 serial communication, external push-button provision and password-protected settings.
How it works
Two flow sensors (inlet and outlet) are wired to one unit. The comparator displays flow from both sensors and raises an alarm when the recovery rate — outlet flow as a percentage of inlet — crosses the set Flow Recovery percentage. The relay can be configured to trip above or below the setpoint. Settings are password protected and five operating modes are available; the source does not describe them.
Features
-
Two-sensor comparison
Monitors two flow sensors, inlet versus outlet, on one device.
-
Recovery-rate alarm
Alarms when the recovery rate crosses the set Flow Recovery percentage, trippable above or below the setpoint.
-
RS485 serial communication
Serial communication over RS485.
-
External push-button provision
Provision for an external push button.
-
Password-protected settings
Configuration is protected by password.
-
Five operating modes
Source states five selectable modes but does not name or describe them.
-
Combined controller and monitor
Described as providing complete flow controller / monitor functionality with an on-board display.
Technical specifications
8 values · 2 groups
These values are transcribed from the manufacturer's datasheet and are pending engineering sign-off. Confirm critical figures with Accumax before specifying.
| Function | |
|---|---|
| Mode function (Mode Select Table) | To monitor two flow sensor (Inlet Vs. Outlet) and Alarm on reducing rate of recovery |
| Measurement & Control settings (Flow comparator Mode, section 1.3) | |
| Input unit selection list | L/S, L/M, L/H, KL/S, KL/M, KL/H, KG/S, KG/M, KG/H |
| Flow recovery percentage (value printed on the setting screen) | 070 %% |
| Output delay timer, Seconds (value printed on the setting screen) | 0010 SECSEC |
| Relay energizer options | HIGHER THEN SET / Lower then set |
| Relay energizer — Higher then set | Relay On when recovery rate is high th[an] present |
| Relay energizer — Lower then set | Relay On when recovery rate is lower than present |
| Entry to setting mode | Press for 2 seconds for setting mode |
Source: UFC1
Applications
- Chemical industries
- Food and sugar industries
- Pharmaceutical industries
- Textile industries
- Ceramic industries
- Paper mills
- Industrial R.O.
- Water supply schemes
- Sewage treatment plants
Frequently asked questions
What does a flow comparator actually do?
It monitors two flow sensors - typically inlet versus outlet - on one unit, displays flow from both, and alarms when the recovery rate crosses the set Flow Recovery percentage.
How many flow sensors can be connected to one unit?
Two, arranged as inlet versus outlet.
What communication interface does it provide?
RS485 serial communication.
Can operators be stopped from changing the recovery setpoint?
Yes, the settings are password protected.
